OPTIMIZED TREAD DESIGN WITH WITH SIPING
Enhance water evacuration for better maneuverability
RGREY NON -MARKING COMPOUND
Provides low ground disturbance for indoor applications
ENGINEERED RUBER COMPOUND
Optimizes tread life on hard surface
DURABLE CAST STEEL WHEEL
Provides ultimate wheel durability
| CODE | TYRE SIZE | RIM SIZE | ACTUAL TYRE DIMENSIONS | TREAD WIDTH | |
|---|---|---|---|---|---|
| OUTSIDE DIAMETER | OVERALL WIDTH | ||||
| Mm | Mm | Mm | |||
| Inch | Inch | Inch | |||
| 10X3(8) | 76.2X203 | 254 | 76.2 | 74 | |
| 10.0 | 3.0 | 2.9 | |||
| 12X4.5(255) | 114.3X255 | 305 | 114.3 | 112 | |
| 12.0 | 4.5 | 4.4 | |||
| 12.5X4.25(267) | 107X267 | 318 | 107 | 105 | |
| 12.5 | 4.2 | 4.1 | |||
| 323X100(280) | 100X280 | 323 | 100 | 93 | |
| 12.7 | 3.9 | 3.7 | |||
| 15X5(318) | 127X318 | 381 | 12.7 | 125 | |
| 15.0 | 5.0 | 4.9 | |||
| 15X5(320) | 127X320 | 381 | 127 | 125 | |
| 15.0 | 5.0 | 4.9 | |||
| 406X125(354) | 125X354 | 406 | 125 | 121 | |
| 16.0 | 4.9 | 4.8 | |||
